-8*10/100M adaptive RJ45 ports
-Follow IEEE802.3 Ethernet and IEEE802.3u Fast Ethernet protocol standard
-Support full-/half-duplex working mode
-Plug and play, flexible adapt to various scenarios
|
Product model |
NS118 |
| IEEE802.3, IEEE802.3u, IEEE802.3x | |
| Network medium |
10Base-T: CAT3 or above UTP 100Base-TX: CAT5 or above UTP |
| Port | 8*10/100M RJ45 LAN port |
| Backplane bandwidth |
1.6Gbps |
| MAC address table | 2K |
| Size | 150×70×22.55mm |
| LED display | 10/100Mbps（LINK/ACT）、Power |
| Forwarding mode | Store and forward |
| Access method | CSMA/CD |
| Power | 5V/600mA |
| Working environment |
Operating temperature: 0°C ~ 40°C Storage temperature: -20°C ~ 70°C Operating humidity: 10% ~ 90%, RH non-condensing Storage humidity: 5% ~ 90%, RH non-condensing |
